HP P6000 Continuous Access Software - Manual (Page 206)

Comments
•
Tru64 UNIX. Replication is not supported when an AdvFS domain spans partitions.
•
Tru64 UNIX. When replicating AdvFS volumes that have heavy I/O, select the option Suspend
source before replication. See
Suspending I/O before replicating AdvFS volumes .
Example
This template was generated to locally replicate one host volume group and mount one of its
components (logical volume). No other template options were selected.
Task Line
// Replicate a host volume group, and mount component(s) to a host. 1
// 2
// Assign some variables that will be used in this job. 3
$source_VolumeGroup_unc1 = SetVariable(%source_VolumeGroup_unc1% 4
$source_host = SetVariable(%source_host%) 5
$mount_host = SetVariable(%mount_host% 6
$source_VG_component_unc1 = SetVariable(%source_VG_component_unc1% 7
// 8
// Validate that resources are as expected. 9
ValidateHost ($source_host) 10
ValidateHost ($mount_host) 11
ValidateSnapshotHostVolumeGroup ($source_VolumeGroup_unc1) 12
// 13
$Rep1 = SnapshotHostVolumeGroup ($source_VolumeGroup_unc1, FULLY_ALLOCATED, SAME, WAIT) onerror
pauseat E1: 14
// 15
// Mount the replicated volume(s) on a host. 16
$HV1 = CreateHostVolumeGroup ($source_VolumeGroup_unc1, $Rep1, $mount_host) onerror pauseat E2: 17
$MP1 = MountVolumeGroupComponent ($HV1, $source_VolumeGroup_unc1, $source_VG_component_unc1,
%mount_point1%) onerror pauseat E3: 18
// 19
// Wait for user to initiate rollback. 20
Pause () 21
// 22
// Rollback. 23
E4: UnmountHostVolume ($MP1) onerror pauseat E4: 24
E3: DeleteHostVolumeGroup ($HV1) onerror pauseat E3: 25
// 26
E2: DeleteStorageVolumes ($Rep1) onerror pauseat E2 27
// 28
Exit (SUCCESS) 29
206 Jobs
