Visual Manager User Interface
101 Network Storage Router M2402 User Guide
Note: To map Fibre Channel devices to any SCSI initiator on the selected bus, a
Target ID must be enabled from the SCSI Bus Configuration Menu. A Target ID should
only be added if there is a SCSI initiator that needs to address Fibre Channel devices.
Each Target ID can be used to store up to 32 Fibre Channel devices.
\
Note: Auto-Assigned and SCC maps cannot be modified, cleared, filled, or have
entries deleted.
Note: Map settings are saved to memory when any button within the page is selected.
SCSI Map settings:
■ Clear Map clears all entries from the current map.
■ Fill Map fills in the current map.
When the map is filled, the display will show the current devices.
■ Remove Gaps removes any incremental gaps in the sequence of LUN listed
in the table.
When the system removes gaps from the table, the LUN are renumbered in
sequential order, starting with LUN 0.
Note: Some operating systems require gaps be removed in the mapping table to
detect all devices.
■ Delete deletes map entries.
To delete a range of LUNs, select the beginning LUN to delete from the
‘from’ drop-down box and select the last LUN to delete from the ‘to’
drop-down box.
■ Discovered Device Entry adds a discovered device to the map.
To add a discovered device to the map, use the drop-down boxes to enter the
settings, and then click Create Entry in the Discovered Device Entry section
of the screen.
