Hardware Module Replacement
191 Network Storage Router M2402 User Guide
Installing a Power Module or Power Bay Cover
To install a power module or power bay cover:
1. If a power module or power bay cover has not been removed, refer to the
preceding procedure, “Removing a Power Module or Power Bay Cover.”
When completed, proceed to Step 2.
2. Remove the new power module from its shipping container and remove all
packing material from around the module (see Figure 112 ).
Caution: Place the module onto a smooth surface and avoid exposure to
direct sunlight, liquids or vapors, excessive heat, risk of accidental dropping,
or other damage.
3. To install a power module, hold the handle 2 shown in Figure 112 , align the
bottom plate of the module beneath the guides of the bay opening, and slide
the module into the power bay until the outer plate of the module is flush
against the front of the router.
Caution: When installing a module, ensure the edges of the bottom plate of
the module are beneath the guides of the bay opening. Failure to properly
install a module may result in damage to the module or router and may void
your service warranty.
To install a power bay cover, carefully slide the cover so that it clips onto the
left side of the power bay. Verify the orientation of the warning message as
seen in
Figure 113 .
4. Tighten the thumbscrews on the power module or power bay cover.
