Installation
48 Network Storage Router M2402 User Guide
SCSI Connections
The router supports Fast/Ultra-2 Narrow/Wide SCSI. The router is factory
configured to support LVD/Single-Ended or HVD (Diff), or a mixture of both
types of SCSI buses. Up to twelve SCSI buses can be attached, using 3 SCSI
modules.
Note: The router must always be installed at the end of SCSI buses.
The router supplies termination power (TERMPWR) to each SCSI bus.
Note: During certain faults, the termination power IC will shut down. It may be
restarted once the fault is cleared.
Caution: During the attachment of high density SCSI cables, note the
orientation of the high-density SCSI port connectors. Connector orientation
failure may result in connector damage.
Caution: LVD/SE and HVD connections must be made on appropriate I/O
modules. Failure to heed this caution may result in damage to equipment.
Caution: Failure to comply with the minimum high-density cable
specifications can result in damage to the router or an operational failure of
the product.
