Serial/Telnet User Interface
138 Network Storage Router M2402 User Guide
Device Mapping
Device mapping allows the user to manipulate maps and associate the selected
hosts with a particular map. Each physical port/bus on the router can have the
following maps:
Each map has a unique name and map ID; one of the maps must be identified as
the “current” map for the router to use.
Maps are viewed, edited, deleted, and cloned in the Device Mapping
Configuration menu.
To access the Device Mapping configuration menu:
1. In the router main menu, select Module Configuration (4).
2. Select a module to configure.
If a Fibre Channel module was selected, the Fibre Channel Configuration
Menu is displayed. To view and change Fibre Channel mappings, select
Change Map Settings (6).
If a SCSI module was selected, the SCSI Configuration Menu is displayed. To
view and change SCSI mappings, select Change Map Settings (8).
Table 3: Device Map Types
Map Type
System/User
Generated Fibre Channel or SCSI
Auto Assigned System Fibre Channel and SCSI
Indexed System Fibre Channel and SCSI
SCC System SCSI
Custom User Fibre Channel and SCSI
