Visual Manager User Interface
63 Network Storage Router M2402 User Guide
Visual Manager Access
Visual Manager (VM) can be accessed from any standard web browser:
1. Connect a 10/100BaseT Ethernet cable to the back of the router.
2. Apply power to the connected SCSI and/or FC devices.
3. After all of the devices have completed their power up routines, apply power
to the router.
4. Apply power to the host computer.
5. Enter the router IP address in the address field of the Web browser of the host
computer.
Note: To access VM, the router must be assigned a valid IP address. The factory
default setting for the IP address allows access on a local area network only. If the
factory default for the IP address is already used by another device on the local
network, the IP address must be changed.
The factory default for the IP address is http://1.1.1.1/
Note: If the IP address of the router is not known or needs to be changed, connect to
the router using a serial connection. The current router IP address is displayed and can
be changed in the serial Ethernet Configuration Menu.
6. Router status information is displayed in the Visual Manager home page. The
home page is accessible to anyone who knows the router IP address.
To access any other menus and screens, the user must enter the authorized
user name and password. The default user name is
root and the default
password is password . This information is required only once per session.
Note: User name and password are case-sensitive. HP recommends changing the user
name and password from the defaults
