Controller LUN Commands
213 Network Storage Router M2402 User Guide
The router returns the LUN Parameters as defined in Table 8 .
All LUNs are reported and will appear in the host map.
Note: In addition to the device LUNs, controller LUNs are also included in the report.
Controller LUN values are displayed at the end of the list. Controller LUN Inquiries
report peripheral device types as 0x0c.
Inquiry Command
The format of the Inquiry Command is shown in Table 9 .
Table 8: Report LUNs Data
Bit/Byte 7 6 5 4 3 2 1 0
0
Most Significant Byte (MSB)
1
LUNS Length List
2
3
Least Significant Byte (LSB)
4
Reserved
5
Reserved
6
Reserved
7
Reserved
Table 9: Format of LUN Inquiry Command
Bit/Byte 7 6 5 4 3 2 1 0
0
Operation Code (Example: 0x12)
1
Reserved EVPD
2
Page Code or Operation Code
3
Reserved
4
Allocation Length
5
Control
