Visual Manager User Interface
98 Network Storage Router M2402 User Guide
Note: Auto-Assigned and SCC maps cannot be modified, cleared, filled, or have
entries removed.
Note: Map settings are saved to memory when any of the buttons within the page are
selected.
Fibre Channel Map settings:
■ Clear Map clears all entries from the current map.
■ Remove Gaps removes any incremental gaps in the sequence of LUN listed
in the table.
When the system removes gaps from the table, the LUN are renumbered in
sequential order, starting with LUN 0.
Note: Some operating systems require gaps be removed in the mapping table in order
to detect all devices.
■ Fill Map fills in the current map.
To use the Fill Map option, expand the Fill Map Priority drop-down box,
select the fill option, and then click Fill Map.
When the map is filled, the display will show the current devices.
■ Delete deletes map entries.
To delete map entries, expand the Delete Map Item LUN drop-down box,
select the LUN, and then click Delete.
To delete a range of LUNs, select the beginning LUN to delete from the
‘from’ drop-down box and select the last LUN to delete from the ‘to’
drop-down box.
■ Discovered Device Entry adds a discovered device to the map.
To add a discovered device to the map, use the drop-down boxes to enter the
settings, and then click Create Entry in the Discovered Device Entry section
of the screen.
