Visual Manager User Interface
99 Network Storage Router M2402 User Guide
■ Manual Device Entry create a map entry for a device that is not yet
discovered or installed.
To add a new device to the map, use the drop-down boxes to enter the
settings, and then click Create Entry in the Manual Device Entry section of
the screen.
SCSI Mapping Tasks
Configuration tasks for SCSI mapping include:
■ Viewing and Changing SCSI Host Information
■ Viewing and Changing SCSI Map Information
Each task is discussed in the following paragraphs.
Viewing and Changing SCSI Host Information
To view or change current SCSI host information:
1. In the Mapping Menu screen, select the desired SCSI module and bus.
2. Click Edit/View in the Host section of the screen.
The SCSI Host Name dialog box is displayed. Current host information is
shown at the top of the dialog box.
3. Enter the new settings and then click Modify.
Figure 53 is an example of the SCSI Host Name configuration dialog box.
Figure 53: SCSI Host Name dialog box
