Addressing Methods and Table Structures
220 Network Storage Router M2402 User Guide
Depending on the configuration, the router supports the Peripheral Device
Addressing method and the Logical Unit Addressing method.
The data shown in Table 22 comes from the FC Configuration Menu. The
administrator enters the node number (number to the left of the colon in Table 22 )
and the router translates the node number into the corresponding AL_PA value
(number to the right of the colon in
Table 22 ).
Table 20: SCSI Logical Unit Addressing
Bit/Byte 7 6 5 4 3 2 1 0
N 1 0 Target
Table 21: Peripheral Device Addressing
Bit/Byte 7 6 5 4 3 2 1 0
N 0 0 Bus
N+1 Target/LUN
Table 22: Arbitrated Loop Node-Number to AL-PA Lookup Table
0:0x01 21:0x2E 42:0x52 63:0x74 84:0xA6 105:0xC9
1:0x02 22:0x31 43:0x53 64:0x75 85:0xA7 106:0xCA
2:0x04 23:0x32 44:0x54 65:0x76 86:0xA9 107:0xCB
3:0x08 24:0x33 45:0x55 66:0x79 87:0xAA 108:0xCC
4:0x0F 25:0x34 46:0x56 67:0x7A 88:0xAB 109:0xCD
5:0x10 26:0x35 47:0x59 68:0x7C 89:0xAC 110:0xCE
6:0x17 27:0x36 48:0x5A 69:0x80 90:0xAD 111:0xD1
7:0x18 28:0x39 49:0x5C 70:0x81 91:0xAE 112:0xD2
8:0x1B 29:0x3A 50:0x63 71:0x82 92:0xB1 113:0xD3
9:0x1D 30:0x3C 51:0x65 72:0x84 93:0xB2 114:0xD4
10:0x1E 31:0x43 52:0x66 73:0x88 94:0xB3 115:0xD5
11:0x1F 32:0x45 53:0x67 74:0x8F 95:0xB4 116:0xD6
12:0x23 33:0x46 54:0x69 75:0x90 96:0xB5 117:0xD9
13:0x25 34:0x47 55:0x6A 76:0x97 97:0xB6 118:0xDA
14:0x26 35:0x49 56:0x6B 77:0x98 98:0xB9 119:0xDC
15:0x27 36:0x4A 57:0x6C 78:0x9B 99:0xBA 120:0xE0
