KROHNE OPTIMASS with MFC 300 EN - Manual (Page 45)

45 www.krohne.com
Dimension of A in mm & inches for all available process connector lengths
A
Connection type mm inches
¼” NPT 256 ±3 10.1 ±0.1
ASME 150 286 ±3 11.3 ±0.1
ASME 300 286 ±3 11.3 ±0.1
ASME 600 295 ±3 11.6 ±0.1
DIN15 PN40 286 ±3 11.3 ±0.1
DIN15 PN63 295 ±3 11.6 ±0.1
15A JIS20K 286 ±3 11.3 ±0.1
DIN10 DIN32676 260 ±3 10.2 ±0.1
½” Tri-Clover clamp 262 ±3 10.3 ±0.1
All dimensions (inches)
S/H 01 S/H 03 S/H 04
A 1 1 1
B 6.3
C 2.4
D1 13.7
D2 10.6
E 4.9
F 5.4
G 3.9
H 6.1
I 7.1
K 5.2
Measuring tube inner diameter 0.05 0.1 0.2
1
depending on process connection. See table for dimensions
