43
Weights
Weight of OPTIMASS 3000 sensor fitted with a typical standard connection in kg (lbs)
6.8 Technical Data
Nominal Flow Rates
Maximum flow rate
Typically 130 % of the nominal flow rate for the sensor size depending on application.
Minimum flow rate
Depending on measuring error required.
Tube materials:
• S 316L
• Hastelloy C22
The meter size has a prefix S or H indicating the tube material.
Secondary pressure containment
• All OPTIMASS 3000 Series meters have secondary containment rated to 30 bar or 435 psi.
Materials of construction
• Connections: SS 316 L or HC22
• Secondary Containment: SS 316 L
• Front end housing and post: SS 316 L
• Converter housing/remote junction box: Epoxy coated aluminium or stainless steel
Size 01 03 04
Kg 12 12 12
lbs 26.4 26.4 26.4
01 03 04
Kg/h 15 100 350
Lbs/min 0.5 3.5 12.5
