100
1 indicates status messages, if any
2 Marker indicates position in the menu/function lists
3 Higher-level menu (with No. in Setup Menu only)
4 Indicate beginning and end of menu/function lists
5 Current menu
6 Not indicated in Menu Mode
7 Next selectable menu
8 Current menu/function (with No. only in Setup Menu)
9 Indicator for factory settings
Factory setting (for info only, unalterable) of current (sub-) function to be changed
Current (sub-) function
Currently set value, unit or function (when selected,shown as white characters on blue
background)
Indicator for allowable range of values
Allowable range of values, only in case of numerical values or next function
Indicator for changing a (sub-) function; allows simple check of changed data when scroll-
ing through the (sub-) function lists.
13
12
15
14
11
10
1
1
2
1
9
13
15
