116
Ref Display Description & Settings
C6.6.4 Password Quick Set
Activates 4-character password for changes in the Quick Setup Menu.
0000 deactivates the password.
C 6.6.5 Password Setup
Activates 4-character password for changes in the Setup Menu and
in the Test Menu.
0000 deactivates the password
C 6.6.6 GDC IR interface
Cancel
Press
g
key, IR-Interface not activated,
andexit this function
Activate
Press
g
key, IR-Sensor is activated,
and accept all changes made up to now
Within the next 60 sec. position the IR-Interface with the suction cups
on the pane of the housing.The correct position is indicated by the
steady bright red LED of the interface, as soon as the red LED and the
IR-Sensor (below the keys on the display) are roughly one above the
other, see Fig. in Sect. 10.2.
C 6.7 Units (units applicable to display and all settings, except for pulse output)
C.6.7.1 Volume flow
• l/s • m³/s • ft³/s • gal/s • IG/s
• l/min • m³/min • ft³/min • gal/min • IG/min
• l/h • m³/h • ft³/h • gal/h • IG/h
• barrel/h
• barrel/day • user-defined unit (free unit)
C.6.7.2 Text free unit
appears only when "free unit“ selected in Fct. C 4.7.01
to set these two functions, see "free unit“ below
C.6.7.3 [m³ / s] * Factor
C.6.7.4 Mass flow
• g/s • kg/s • t/min • lb/s • ST/min (= Short Ton)
• g/min • kg/min • t/h • lb/min • ST/h
• g/h • kg/h • lb/h • LT/h (= Long Ton)
• user-defined unit (free unit)
C.6.7.5 Text free unit
appear only when "free unit“ selected in Fct. C 6.7.4
to set these two functions, see "free unit“ below
C.6.7.6 [kg / s] * Factor
C.6.7.7 Flow Speed • m/s or • ft/s
C.6.7.8 No Function
C.6.7.9 Temperature • K • °C • °F
C.6.7.10 Volume
• ml • l • hl • m³ • in³ • ft³ • yd³
• gal • IG • barrel • user-defined unit (free unit)
C.6.7.11 Text free unit
• appear only when "free unit“ selected in Fct. C 6.7.10
• to set these two functions, see "free unit“ below
C.6.7.12 [m³] * Factor
C.6.7.13 Mass
• mg • g • kg • t • oz • lb
• ST (Short Ton) • LT (Long Ton) • user-defined unit (free unit)
C.6.7.14 Text free unit
• appear only when "free unit“ selected in Fct. C 6.7.13
• to set these two functions, see "free unit“ below
C.6.7.15 [kg] * Factor
