44

Dimensions

1

Compact version

2

Remote Version

All dimensions (mm)

S/H 01

S/H 03

S/H 04

A

1

1

1

B

160

C

60

D1

348

D2

269

E

123.5

F

137

G

98.5

H

156

I

180

K

132

Measuring tube inner diameter

1.2

2.6

4.0

1

depending on process connection. See table for dimensions

1

2

E

A

B

C

F

G

D1

A

B

C

D2

G

3

H

K

I
