APPENDIX
137 137 137 137
Specification
Test Frequency LCR-8101G DC, AC:20Hz~1MHz
LCR-8105G DC, AC:20Hz~5MHz
LCR-8110G DC, AC:20Hz~10MHz
Basic Accuracy R,Z,X,G,Y,B,L,C ±0.1%@1kHz
R&G Accuracy
When Qx≧0.1, multiply Ae by ( ) 2 Q 1+ for R, G
accuracies.
Measurable
Parameters Rac, Rdc, Rs, Rp, Z, Ls, Lp, D, G, B, θ, Cp, Cs, Q, Y, X
R,Z,X 0.1mΩ~100MΩ Measurement
Range
G, Y, B 10ns~1ks
L 0.1nH~100kH
C 0.01pF~1F
D 0.00001~1000
Q 0.01~9999.9
Rdc 0.01mΩ~100MΩ
Ɵ -180°~+180°
Parallel C+G, L+G, B+G, B+Q, B+D, B+R Equivalent
Circuit
Series X+R, X+D, X+Q
Series & Parallel C+R, C+D, C+Q, L+R, L+D, L+Q
Polar Form Z + Phase Angle, Y + Phase Angle
Input Impedance 100Ω
Measurement
Speed
DC Max:30ms; Fast:60ms;
Medium:120ms; Slow:900ms
AC≤100Hz Max:600ms; Fast:650ms;
Medium:1.2s; Slow:1.3s
AC≤2kHz Max:120ms; Fast:180ms;
Medium:470ms; Slow:600ms
AC>2kHz Max:75ms; Fast:150ms;
Medium:450ms; Slow:600ms
AC=1MHz
(LCR-8101G) Max:120ms; Fast:150ms;
Medium:470ms; Slow:620ms
AC≥1~5MHz
(LCR-8105G) Max:120ms; Fast:150ms;
Medium:470ms; Slow:620ms
LCR-8000G Series User Manual
138 138 138 138
AC≥1~10MHz
(LCR-8110G) Max:120ms; Fast:150ms;
Medium:470ms; Slow:620ms
LCR-8101G DC:0.01V~2V
AC: 20Hz~1MHz: 0.01V~2Vrms
LCR-8105G DC:0.01V~2V
AC 20Hz~≤3MHz:0.01V~2Vrms
AC >3MHz~5MHz:0.01V~1Vrms
Drive Signal Level
LCR-8110G DC:0.01V~2V
AC 20Hz~≤3MHz:0.01V~2Vrms
AC >3MHz~10MHz:0.01V~1Vrms
LCR-8101G DC:100uA~20mA
AC 20Hz~1MHz:100uA~20mA rms Drive Signal Short
Circuit Current
LCR-8105G DC:100uA~20mA
AC:20Hz~≦3MHz:100uA~20mArms
AC>3MHz~5MHz:100uA~10mA
rms
LCR-8110G DC:100uA~20mA
AC:20Hz~≦3MHz:100uA~20mArms
AC>3MHz~10MHz:100uA~10mA
rms
Drive Signal
Resolution When the drive signal level is <1V: 1mV
When the drive signal level is ≥1V: 10mV
LCR-8101G DC:± 2% ± 5mV
AC20Hz~1MHz:± 2% ± 5mV
LCR-8105G DC: ± 2% ± 5mV
AC:20Hz~≤1MHz:± 2% ± 5mV
AC:>1MHz~5MHz:± 5% ± 10mV
Drive Signal
Open Circuit
Accuracy
LCR-8110G DC: ± 2% ± 5mV
AC:20Hz~≤1MHz:± 2% ± 5mV
AC:>1MHz~10MHz:± 5%±10mV
