Running Measurement
Select Single measurement
Background The data capture can be manually controlled
(Single) or automatically updated (Repetitive).
In single measurement, the measurement is
activated by pressing the Trigger key.
In repetitive measurement, the measurement is
automatically done and the display is updated
according to the speed (timing) setting.
Panel operation 1. Press the Sing/Rep key repeatedly
until the “Single Shot Mode”
message appears on the display.
Sing/Rep
Single Shot Mode
2. The measurement update indicator (*) does not
appears at the top left corner of the display.
MEASUREMENT MODE
nS
D
7
3. To capture measurement data, press
the Trigger key. The measurement
update indicator (*) blinks and the
measurement result is updated on
the display.
Trig
MEASUREMENT MODE
0.01234
0.2179
nS
D
*7
–
LCR-8000G Series User Manual
56 56 56 56
Select Repetitive measurement
Background The data capture can be manually controlled
(Single) or automatically updated (Repetitive).
In single measurement, the measurement is
activated by pressing the Trigger key.
In repetitive measurement, the measurement is
automatically done and the display is updated
according to the speed (timing) setting.
Panel operation 1. Press the Sing/Rep key repeatedly
until the “Repetitive Mode” message
appears on the display.
Sing/Rep
Repetitive Mode
2. The measurement update indicator (*) keeps
blinking and the measurement result is updated
on the display.
MEASUREMENT MODE
0.01234
0.2179
nS
D
*7
–
3. Press the Left/Right key repeatedly
to move the cursor to measurement
speed.
Speed Slow
4. Press the Up/Down key repeatedly
to select the time per update.
