REMOTE CONTROL
113
113
113
113
*stb?
Returns the current contents of the Status Byte
with the Master Summary bits as an integer in the
range 0 to 255. Bit 6 represents Master Summary
Status rather than Request Service.
*trg
Triggers a direct measurement, but does not return
the results to the controller. This is the same as a
GET (Group Execute Trigger) command.
*wai
Command has no effect as commands are
processed sequentially.
Measurement command
:dump-bmp
Returns the current display as a windows
compatible bitmap.
:beep
:beep?
Sets or returns the buzzer condition.
Set parameter: off (disabled), pass (beeps when
passed), fail (beeps when failed)
Return parameter: 0 (off), 1 (pass), 2 (fail)
:loc-trig
Turns On/Off local triggering in remote control
Parameter: on (local control), off (remote control)
:meas:equ-cct
:meas:equ-cct?
Selects or returns equivalent circuit.
Send parameter: ser, par
Return parameter: 0 (parallel), 1 (series)
:meas:freq
:meas:freq?
Sets or returns frequency of AC measurement in
Hz.
Parameter example: (1kHz) 1k, 1000 Hz, 1E3
:meas:func
Selects first or second AC measurement function.
Parameter: c, l, x, b, z, y, q, d, r, g
Example: :meas:func:c;d (C+D measurement)
:meas:func:major
?
Returns the first AC function.
Parameter: 0 (C), 1 (L), 2 (X), 3 (B), 4 (Z), 5 (Y)
LCR-8000G Series User Manual
114
114
114
114
:meas:func:minor
?
Returns the second AC function.
Parameter: 0 (Q), 1 (D), 2 (R), 3 (G)
If the first function is Z or Y, this command returns
the last non-polar setting
:meas:hi-lim
:meas:hi-lim?
Sets or returns scale high limit as percentage.
Example: :meas:hi-lim 5.0 (+5.0%)
:meas:lev
:meas:lev?
Sets or returns drive level for currently selected
test.
Parameter example: (200mV) 0.2V, 200m
:meas:limit
:meas:limit?
Sets or returns percentage, absolute or delta scale
limits.
Send parameter: abs (absolute), perc (percentage),
delta (delta)
Return parameter: 0 (absolute), 1 (percentage), 2
(delta)
:meas:lo-lim
:meas:lo-lim?
Sets or returns scale low limit as percentage.
Example: :meas:hi-lim –5.0 (–5.0%)
:meas:nom
:meas:nom?
Sets or returns nominal value for scale.
Send parameter: according to the active unit (1e-6f
= 1uF)
Return parameter example: .10000000e-1 = 10mH
:meas:range
:meas:range?
Selects or returns auto-ranging or range-hold on
range N.
Send parameter: auto, hold, 1 ~ 7
Return parameter: 0 (auto), 1 ~ 7
:meas:scale
:meas:scale?
Shows or hides the scale bar or returns the status.
Send parameter: on, off
Return parameter: 0 (scale hidden), 1 (scale visible)
