GW Instek LCR-8000G Series User Manual

Page 15

GETTING STARTED

10b. Select
Repetitive
measurement

Press the Sing/Rep key to select
Repetitive (automatic trigger)
measurement. Press the Left/Right arrow
key and move the cursor to Speed. Press
the Up/Down key to select the speed.

Page56

11a. Select
Absolute
measurement

Press F5 (Abs/%/∆) to select Abs. Press
the Left/Right key to move the cursor to
Lo (Low limit). Use the numerical and
unit keys to set the Low limit. Repeat this
for Hi (Hi limit) as well.

Page66

11b. Select
Percentage
measurement

Press F5 (Abs/%/∆) to select %. Press the
Left/Right key to move the cursor to the
Nominal value. Use the numerical and
unit keys to set the numerical level. Then
move the cursor to Lo (Low limit) and set
the percentage. Repeat this for Hi (Hi
limit) as well. To save the latest
measurement result as Nominal, press F6
(Save Nom).

Page67

11c. Select Delta
measurement

Press F5 (Abs/%/∆) to select ∆. Press the
Left/Right key to move the cursor to the
Nominal value. Use the numerical and
unit keys to set the numerical level. Then
move the cursor to Lo (Low limit) and set
the Lo value difference. Repeat this for Hi
(Hi limit) as well. To save the latest
measurement result as Nominal, press F6
(Save Nom).

Page68

Optional settings To hide the drive Voltage/Current, press

the Code key, type 80, then press Enter.

Set the Range (internal setting) to Auto,
use the Left/Right key to move the cursor
and Up/Down key to change the setting.

Page57

Page51

LCR-8000G Series User Manual

Pass/Fail test (Multiple step)

Step

Description

Details

1. Connect fixture Connect the fixture to the DUT.

Page24

2. Set buzzer
sound

Press the Menu key, then F5 (System).
Press the Up/Down arrow key to move
the cursor to Beep, then use the
Left/Right key to select setting (Off
recommended).

Page72

3. Set Average

Press the Menu key, then F5 (System).
Press the Up/Down arrow key to move
the cursor to Average, then use the
numerical keys to enter an average
number (1-256). Press enter to confirm the
number.

Page73

4. Enter multiple
step mode

Press the Menu key, then F3 (Multi step). Page74

5. Select
measurement
item

Press the arrow keys to move the cursor
to Step 01 Func. Press F1 (Prog)
repeatedly to select the item.

Page76

6a. Set
parameters

Press the arrow keys to move the cursor
to the parameters below. Use the
numerical and unit keys for editing values
or F1 (Prog) for selecting options.

Page76

6b. Add steps

Move the cursor to the first empty step
and press F1 (Prog).

Page76

6c. Copy to the
next step

Press F2 (Copy). The selected step
contents are copied and inserted to the
next step.

Page79

6d. Delete step

Press F3 (Delete). The selected step is
deleted.

Page79

7. Save program Press F4 (Save). The edited program is

saved.

Page83
