Chapter 4
_________________________________________________________________________
________________________________________________________________________
BE6027-12 LumaSoft Gas Software LumaSense Technologies A/S
7810 and 7860 Page 96 of 194
A specific time interval can be selected by entering date and time in the
two fields: From Date and To Date, see Figure 4.65.
Figure 4.65 Select time interval for historic data plotting.
Click OK to display the historical data in a graph.
The functions of the icons in the historical window are the same as in
the Real Time Window described in Section 4.2.2.7 .
To continue the measurements performed in the specific task, press the
green arrow icon or select Start in the Measurement drop down
menu, see Figure 4.3 .
To display the incoming measuring data (real time data) select the
icon.
