Chapter 2
_________________________________________________________________________
________________________________________________________________________
BE6027-12 LumaSoft Gas Software LumaSense Technologies A/S
7810 and 7860 Page 22 of 194
Decimal
Address
DIP switch setting
(looking onto rear)
1309 multipoint
sampler
15 0 0 0 0 1 1 1 1 1
13 0 0 0 0 1 1 0 1 2
Table 2.4 Setting the 1309 address
2.2.11 Setting up a Multipoint System with Multipoint Sampler
and Doser - INNOVA 1303.
The 1303(s) is connected to the Gas Monitor using IEEE-488 cable(s).
To avoid data errors, this cable must conform to the specifications laid
down in the IEEE-488 standard, particularly with regard to length,
connector type and “daisy-chaining”. LumaSense can supply the correct
cables, Cable order no. AO0265 (2m) or WL0845 (1m).
Caution: To avoid permanently damaging the delicate electronics in a
1303 or the Monitor, you must ensure that all IEEE-488 instruments are
switched off before connecting or disconnecting the interface cables.
The IEEE–488 address of each 1303 in the system must be set before
communication with the PC can occur. The address is set using the eight
DIP switches located on the back panel of the 1303. The decimal
address of the instrument is expressed as a binary number, the MSD
(Most significant DIP switch) being to the left looking onto the back
panel. Table 2.5 will guide you.
Decimal
Address
DIP switch setting
(looking onto rear)
1303 multipoint
sampler
15 0 0 0 0 1 1 1 1 1
13 0 0 0 0 1 1 0 1 2
12 0 0 0 0 1 1 0 0 3
11 0 0 0 0 1 0 1 1 4
Table 2.5 Setting the 1303 address
2.3 Setting-up User Accounts
Setting up user accounts can be performed by the administrator only.
After starting the LumaSoft Gas application the User Authentication
window opens, where you authenticate yourself as the administrator by
specifying the administrator user name and password.
