Chapter 1
_________________________________________________________________________
________________________________________________________________________
BE6027-12 LumaSoft Gas Software LumaSense Technologies A/S
7810 and 7860 Page 10 of 194
The display above is used through-out this manual. It assists you
displaying the text on screen and by indicating which of the push-
buttons can and should be pressed.
In general, the push-buttons shown above are used to navigate through
the various modes possible within the Monitor but are described in more
detail below:
These push-buttons are illustrated as S1, S2 and S3. They correspond
to the key and their position on the instrument.
These select push-buttons enable you to select one of the options
displayed.
This group of 5 push-buttons are referred to in this manual collectively
as the direction keys. The symbols below are used to simplify the
instruction in this manual.
▲ & ▼ enable you to increase & decrease numbers, respectively, or to
go to the Previous & Next Displays, respectively.
◄ & ► enable you to move across number fields or go to the Previous &
Next gases, respectively.
↵ , depending on the situations, acts as an “Enter” or “Go To Head” key.
Memory Function push-buttons are always represented with the name of
the push-button enclosed in a box which is shaded-in.
SYSTEM Text that appears on the display screen is shown in an open
shaded box, using UPPER case letters.
FORMAT System General Clock
When referring to any part of the Set-up “tree”, the text is shown
in open shaded boxes with the same typeface as that used in the
“tree”.
S1 S2 S3
