Chapter 1
_________________________________________________________________________
________________________________________________________________________
BE6027-12 LumaSoft Gas Software LumaSense Technologies A/S
7810 and 7860 Page 9 of 194
1.2 Screens
The information displayed on screen is presented in this manual as
shown below:
Radio push-buttons: these are not illustrated above, but are commonly
used in the software. They act as a toggle function when several options
are available, but only one can be selected at a time.
1.3 Stand-alone Use
In some situations, it may be necessary to set up the Monitor without
connecting it to a PC. The way these instructions are presented is shown
below:
SELECT SET-UP BRANCH
MEASUREMENT FORMAT CONFIGURATION
1. Menu bar option e.g. File
2. Pull down menu option Export Task
3. Index card e.g. Gas
4. Group e.g. Gas Setup
5. Select Field e.g. Select SIT
6. Check box used to select options
7. Soft-key e.g. Read Filter Info
