4.4 View Measurement alarms
A description of measurement alarms can be found in Section 3.2.4 .
To show the alarms in the numeric window check the tick box Show
Alarm, refer to Figure 4.81.
An extra Alarm column for every filter is then shown.
If an alarm occurred for a measured value it is shown as either High,
High High, Low or Low Low in the Alarm column, see Figure 4.81.
Figure 4.81 Alarms shown in numeric display
The Measurement Alarms view can be switched on/off by using the
View menu pull-down Alarms Window, see Figure 4.82 .
