Channel 3 Pressure
Float
Channel3/Pressure/3500100
Channel 3 Gas Monitor Air flag
Boolean Channel3/GasMonitor/Airflag/3500200
Channel 3 Gas Monitor Error flag
Boolean Channel3/GasMonitor/Errorflag/3500300
Channel 3 Monitor Display Error Message
Boolean Channel3/GasMonitor/MonitorDisplayErrorMessage/3500500
Channel 3 Monitor Display Warning Message
String
Channel3/GasMonitor/MonitorDisplayWarningMessage/3500600
Channel 3 Gas Monitor Warning flag
String
Channel3/GasMonitor/Warningflag/3500400
Channel 3 Multiplexer error flag
Boolean Channel3/Multiplexer/errorflag/3600100
Channel 3 Multiplexer warning flag
Boolean Channel3/Multiplexer/warningflag/3600200
Channel 3 Multiplexer error number
Long
Channel3/Multiplexer/errornumber/3600300
Channel 3 Multiplexer warning number
Long
Channel3/Multiplexer/warningnumber/3600400
Channel 3 Multiplexer Error Description
String
Channel1/Multiplexer/ErrorDescription/3600600
Channel 3 Multiplexer Warning Description
String
Channel1/Multiplexer/WarningDescription/3600700
Channel 4 Gas A Concentration
Float
Channel4/GasA/Concentration/4010100
Channel 4 Gas A Alarm HH occurred
Boolean Channel4/GasA/AlarmHHOccurred/4010200
Channel 4 Gas A Alarm H occurred
Boolean Channel4/GasA/AlarmHOccurred/4010300
Channel 4 Gas A Alarm L occurred
Boolean Channel4/GasA/AlarmLOccurred/4010400
Channel 4 Gas A Alarm LL occurred
Boolean Channel4/GasA/AlarmLLOccurred/4010500
Channel 4 Filter A alignment error flag
Boolean Channel4/FilterA/AlignmentErrorFlag/4010600
Channel 4 Gas B Concentration
Float
Channel4/GasB/Concentration/4020100
Channel 4 Gas B Alarm HH occurred
Boolean Channel4/GasB/AlarmHHOccurred/4020200
Channel 4 Gas B Alarm H occurred
Boolean Channel4/GasB/AlarmHOccurred/4020300
Channel 4 Gas B Alarm L occurred
Boolean Channel4/GasB/AlarmLOccurred/4020400
Channel 4 Gas B Alarm LL occurred
Boolean Channel4/GasB/AlarmLLOccurred/4020500
Channel 4 Filter B alignment error flag
Boolean Channel4/FilterB/AlignmentErrorFlag/4020600
Channel 4 Gas C Concentration
Float
Channel4/GasC/Concentration/4030100
Channel 4 Gas C Alarm HH occurred
Boolean Channel4/GasC/AlarmHHOccurred/4030200
Channel 4 Gas C Alarm H occurred
Boolean Channel4/GasC/AlarmHOccurred/4030300
Channel 4 Gas C Alarm L occurred
Boolean Channel4/GasC/AlarmLOccurred/4030400
Channel 4 Gas C Alarm LL occurred
Boolean Channel4/GasC/AlarmLLOccurred/4030500
Channel 4 Filter C alignment error flag
Boolean Channel4/FilterC/AlignmentErrorFlag/4030600
Channel 4 Gas D Concentration
Float
Channel4/GasD/Concentration/4040100
Channel 4 Gas D Alarm HH occurred
Boolean Channel4/GasD/AlarmHHOccurred/4040200
Channel 4 Gas D Alarm H occurred
Boolean Channel4/GasD/AlarmHOccurred/4040300
Channel 4 Gas D Alarm L occurred
Boolean Channel4/GasD/AlarmLOccurred/4040400
Channel 4 Gas D Alarm LL occurred
Boolean Channel4/GasD/AlarmLLOccurred/4040500
Channel 4 Filter D alignment error flag
Boolean Channel4/FilterD/AlignmentErrorFlag/4040600
Channel 4 Gas E Concentration
Float
Channel4/GasE/Concentration/4050100
Channel 4 Gas E Alarm HH occurred
Boolean Channel4/GasE/AlarmHHOccurred/4050200
Channel 4 Gas E Alarm H occurred
Boolean Channel4/GasE/AlarmHOccurred/4050300
Channel 4 Gas E Alarm L occurred
Boolean Channel4/GasE/AlarmLOccurred/4050400
Channel 4 Gas E Alarm LL occurred
Boolean Channel4/GasE/AlarmLLOccurred/4050500
Channel 4 Filter E alignment error flag
Boolean Channel4/FilterE/AlignmentErrorFlag/4050600
Channel 4 Gas W Concentration
Float
Channel4/GasW/Concentration/4060100
Channel 4 Gas W Alarm HH occurred
Boolean Channel4/GasW/AlarmHHOccurred/4060200
Channel 4 Gas W Alarm H occurred
Boolean Channel4/GasW/AlarmHOccurred/4060300
Channel 4 Gas W Alarm L occurred
Boolean Channel4/GasW/AlarmLOccurred/4060400
Channel 4 Gas W Alarm LL occurred
Boolean Channel4/GasW/AlarmLLOccurred/4060500
Channel 4 Filter W alignment error flag
Boolean Channel4/FilterW/AlignmentErrorFlag/4060600
Channel 4 Pressure
Float
Channel4/Pressure/4500100
Channel 4 Gas Monitor Air flag
Boolean Channel4/GasMonitor/Airflag/4500200
Channel 4 Gas Monitor Error flag
Boolean Channel4/GasMonitor/Errorflag/4500300
Channel 4 Gas Monitor Warning flag
Boolean Channel4/GasMonitor/Warningflag/4500400
