Chapter 4
_________________________________________________________________________
________________________________________________________________________
BE6027-12 LumaSoft Gas Software LumaSense Technologies A/S
7810 and 7860 Page 82 of 194
Figure 4.46 Configuration of graph window properties
The number of decimals on the measured values can be selected in the
field selection: Y Axis Decimal places.
The time interval (X Interval) on the X-axis can be set to days, hours,
minutes or seconds.
Back Color, Cursor Color, Text Color and Font etc. can be changed
by pressing the appropriate grey squares.
Gradient Mode gives a shading of a dark background color.
Grid Visible turns on/off the grid.
User Events turns on/off the display of user events (see Section
4.2.2.7 ).
Press Finish when the configuration is completed.
