<7. Startup>
7-4
IM 11M12A01-02E
7.4.2
Display Configuration (for Oxygen Analyzer)
Figure 7.3.1 shows the configuration. A password the displays positioned below enables display
“Execution/Setup” to be protected. If a password has not been set, press the [Enter] key to
proceed to the next panel display. The [Home] key enables you to return to “Execution/Setup
display” from any panel display.
F7.3.1E.ai
[Basic panel display]
[Detailed-data display]
[Execution/Setup display]
[Trend Graph display]
[Password Entry display]
Returns to the
Execution/Setup
display.
Returns to the
Execution/Setup
display.
Returns to the
Execution/Setup
display.
Maintenance panel
display
Commissioning
(Setup) display
mA-output setup
mA-output1
mA-output2
Set presets
Alarms setup
Hysteresis
Contact delay
Setpoints
Contact Output setup
Contact Input setup
Others
Clock
Averaging
Fuel setup
Passwords
Defaults
Display item
Trend graph
Auto return time
Language
Calibration setup
Mode
Points
Zero and Span gas
conc.
Timing
Blow back setup
mA-output loop check
Contact check
Calibration execution
Blow back execution
Reset panel display
Display setup
Returns to the
Execution/Setup
display.
Returns to the
Execution/Setup
display.
Figure 7.3.1 Display Configuration
8th Edition : Jan.13,2012-00
