<2. Specifications>
2-10
IM 11M12A01-02E
8th Edition : Jan.13,2012-00
F2-4E.ai
Rc1/2(Note2)
Approx. 351
180
Detector(ZR22G)
Ø52 over
Ш30
Ш60.5
Reference gas inlet Rc1/4 or 1/4NPT
Calibration gas inlet Rc1/4 or 1/4NPT
High temperature
Probe SiC pipe
110
48
25
170
Approx. 215
(Insertion length) (Note1)
Approx. 100
69
Approx. 48
C
(Note 1) L= 0.5、0.6、0.7、0.8、0.9、
1.0、1.5(m)
(Note 2) Sample gas outlet
(if the sample gas pressure is negative,
connect the auxiliary ejector.)
Ø124±3
85
Sample gas outlet
Flange provided
by customer
Unit: mm
L
t
Flange (Thickness 5)
JIS 5K 32 FF equivalent
Gasket (Thickness 1.5)
Flange <1>
Ø60.5
ØB
ØA
Pipe hole (2- G1/2, 2-1/2NPT, etc)
ШA
Ш1
15
Flange<1>
A
B
C
t
JIS 5K 50 FF SUS304
155
130
4 - Ø15
14
JIS 10K 65 FF SUS304
175
140
4 - Ø19
18
JIS 10K 80 FF SUS304
185
150
8 - Ø19
18
JIS 10K 100 FF SUS304
210
175
8 - Ø19
18
ANSI Class 150 4 RF SUS304
228.6
190.5
8 - Ø19
24
ANSI Class 150 3 RF SUS304
190.5
152.4
4 - Ø19
24
ANSI Class 150 2 RF SUS304
152.4
120.6
4 - Ø19
19
JPI Class 150 4 RF SUS304
229
190.5
8 - Ø19
24
JPI Class 150 3 RF SUS304
190
152.4
4 - Ø19
24
DIN PN10 DN50A SUS304
165
125
4 - Ш18
18
