<8. Detailed Data Setting>
8-10
IM 11M12A01-02E
Output contact 1

Output contact 2
 Output contact 3
 lnput contacts
Enter
Contact setup
F8.7E.ai
Enter
Alarms

Others
 During power-off the
contact is open and
in condition it is Open
Output contact 1
F8.8E.ai
Figure 8.6 Contact Setup Display Figure 8.7 Output Contact 1 Display
Warm up: ON
 Range change: OFF
 Calibration: OFF
 Maintenance: ON
 Blow back: OFF
 Temp.input high: OFF
 Cal.gas press.low: OFF
 Process up set: OFF Enter
Contact1
Others
F8.9E.ai
Figure 8.8 “Contact1 Others” Display
