<3. Installation>
3-12
IM 11M12A01-02E
8th Edition : Jan.13,2012-00
(2) Mount the automatic calibration unit. Remove the U-bolt from the automatic calibration unit
and attach the unit on the wall with four screws. When setting it with M5 bolts, use washers.
F3-16_1E.ai
4-Φ6.5
Figure 3.17 Wall Mounting
