<10. Other Functions>
10-13
IM 11M12A01-02E
Table 10.5 Initialization Items and Default Values - Part 2
Item Initialization Parameter Default setting
Alarm data
Alarm setting
Parameter
Oxygen
concentration
Hysteresis 0.1 vol%O
2
Delayed action of alarm contact 3 seconds
Alarm set value
High-high alarm OFF
Alarm value of High-high alarm 100 vol%O
2
High limit alarm OFF
Alarm value of High limit alarm 100 vol%O
2
Low limit alarm OFF
Alarm value of Low limit alarm 0 vol%O
2
Low-low alarm OFF
Alarm value of Low-low alarm 0 vol%O
2
Contacts
Output contact 1
Alarm OFF
Other settings
Warm-up ON
Output range now being switched OFF
Now calibrating
OFF
Now maintenance servicing ON
Blow back OFF
High limit temp. alarm OFF
Calibration gas press. drop OFF
Gas leak detection OFF
Contact output action Open
Output contact 2
Alarm OFF
Other settings
Warm-up OFF
Output range switching OFF
Now calibrating ON
Now maintenance servicing OFF
Blow back OFF
High limit temp. alarm OFF
Calibration gas press. drop OFF
Gas leak detection OFF
Contact output action Closed
Output contact 3
Alarm
High-high alarm OFF
High limit alarm ON
Low limit alarm ON
Low-low alarm OFF
Calibration Coefficient Alarm OFF
Startup power stabilization
timeout
OFF
Error OFF
Other settings OFF
Contact output Closed
Output contact 4
Alarm Error ON
Other settings OFF
Contact output Closed (Fixed)
Input contact 1
Input contact 2
Function OFF
Action Closed
8th Edition : Jan.13,2012-00
