Page 71

ICE Module

4.11 LAN (Local Area Network)

All COM Express modules provide at least one LAN port with the minimum capability

of 10/100BaseTx Ethernet and optional 10/100/1000BaseT Gigabit Ethernet compliant

to the IEEE 802.3ab specification.

The LAN interface of the COM Express module consists of 4 pairs of low voltage

differential pair signals designated from 'GBE0_MDI0' (+ and -) to 'GBE0_MDI3' (+ and

-) plus additional control signals for link activity indicators. These signals can be used

to connect a 10/100/1000BaseT RJ-45 connector with integrated or external isolation

magnetics to the carrier board. The corresponding LAN differential pair and control

signals can be found on the modules connector rows A and B.

4.11.1 Signal Description

Table 4-20 shows COM Express Ethernet signals, including pin number, signals, I/O,

power plane, terminal resistors, damping resistors and descriptions.

Table 4-20: Ethernet signals description

Pin

Signal

I/O

Description

A13
A12

GBE0_MDI0+
GBE0_MDI0-

I/O

Media Dependent Interface (MDI) differential pair 0. The
MDI can operate in 1000, 100, and 10Mbit/sec modes.

A10
A9

GBE0_MDI1+
GBE0_MDI1-

I/O

Media Dependent Interface (MDI) differential pair 1. The
MDI can operate in 1000, 100, and 10Mbit/sec modes.

A7
A6

GBE0_MDI2+
GBE0_MDI2-

I/O

Media Dependent Interface (MDI) differential pair 2. The
MDI can operate in 1000, 100, and 10Mbit/sec modes.

A3
A2

GBE0_MDI3+
GBE0_MDI3-

I/O

Media Dependent Interface (MDI) differential pair 3. The
MDI can operate in 1000, 100, and 10Mbit/sec modes.

A14 GBE0_CTREF

REF

Reference voltage for carrier board Ethernet channel 0
magnetics center tap. The reference voltage is
determined by the requirements of the module's PHY
and may be as low as 0V and as high as 3.3V.

A8 GBE0_LINK#

O 3.3V OD
CMOS

Ethernet controller 0 link indicator, active low.

A4 GBE0_LINK100#

O 3.3V OD
CMOS

Ethernet controller 0 100Mbit/sec link indicator, active
low.

A5

GBE0_LINK1000
#

O 3.3V OD
CMOS

Ethernet controller 0 1000Mbit/sec link indicator, active
low.

B2 GBE0_ACT#

O 3.3V OD
CMOS

Ethernet controller 0 activity indicator, active low.
