Page 39
ICE Module
The PCI Express interface of the COM Express Type 2 module consists of up to 6
lanes, each with a receive and transmit differential signal pair designated from
PCIE_RX0 (+ and -) to PCIE_RX5 (+ and -) and correspondingly from PCIE_TX0 (+
and -) to PCIE_TX5 (+ and -). According to the PCI Express specification, these six
lanes can be configured as several PCI Express x1 links or to a combined x4 link plus
two x1 links. These configuration possibilities are based on the COM Express
module's chipset capabilities.
4.2.1 Signal Description
Table 4-5: PCI Express Signal Descriptions
Pin Signal I/O Description
B68
B69 PCIE_RX0+
PCIE_RX0- I PCIe Port 0. Receive Input differential pair.
A68
A69 PCIE_TX0+
PCIE_TX0- O PCIe Port 0. Transmit Output differential pair.
B64
B65 PCIE_RX1+
PCIE_RX1- I PCIe Port 1. Receive Input differential pair.
A64
A65 PCIE_TX1+
PCIE_TX1- O PCIe Port 1. Transmit Output differential pair.
B61
B62 PCIE_RX2+
PCIE_RX2- I PCIe Port 2,. Receive Input differential pair.
A61
A62 PCIE_TX2+
PCIE_TX2- O PCIe Port 2. Transmit Output differential pair.
B58
B59 PCIE_RX3+
PCIE_RX3- I PCIe Port 3.. Receive Input differential pair.
A58
A59 PCIE_TX3+
PCIE_TX3- O PCIe Port 3. Transmit Output differential pair.
B55
B56 PCIE_RX4+
PCIE_RX4- I PCIe Port 4. Receive Input differential pair.
A55
A56 PCIE_TX4+
PCIE_TX4- O PCIe Port 4. Transmit Output differential pair.
B52
B53 PCIE_RX5+
PCIE_RX5- I PCIe Port 5. Receive Input differential pair.
A52
A53 PCIE_TX5+
PCIE_TX5- O PCIe Port 5. Transmit Output differential pair.
A88
A98 PCIE_CLK_REF+
PCIE_CLK_REF- O PCIe Reference Clock for all COM Express
PCIe lanes, and for PEG lanes
B66 WAKE0# I PCIE PCIe Wake Event: Sideband wake-up signal.
A49 EXCD0_CPPE# I 3.3V
CMOS
ExpressCard capable card request, slot 1.
B48 EXCD1_CPPE# I 3.3V
CMOS
ExpressCard capable card request, slot 2.
A48 EXCD0_PERST# O 3.3V
CMOS
ExpressCard reset, slot 1.
B47 EXCD1_PERST# O 3.3V
CMOS
ExpressCard reset, slot 2.
