IEI Integration ICE-DB-9S User Manual
Page 125
ICE Module
Page 112
0.01U
Cap
A25
A26
SATA2_RX+
SATA2_RX-
- 0.01U
Cap
0.01U
Cap
Directly connect to SATA Connector
A22
A23
SATA2_TX+
SATA2_TX-
- 0.01U
Cap
0.01U
Cap
Directly connect to SATA Connector
B25
B26
SATA3_RX+
SATA3_RX-
- 0.01U
Cap
0.01U
Cap
Directly connect to SATA Connector
B22
B23
SATA3_TX+
SATA3_TX-
- 0.01U
Cap
0.01U
Cap
Directly connect to SATA Connector
A28 SATA_ACT#
PU
-
Please refer to ICE Demo Board
If unused, these signals can be left as NC.
-
Pin
Signal
PU/PD
Series
Notes
V
A46
A45
USB0+
USB0-
- -
Directly connect to USB Device
B46
B45
USB1+
USB1-
- -
Directly connect to USB Device
A43
A42
USB2+
USB2-
- -
Directly connect to USB Device
B43
B42
USB3+
USB3-
- -
Directly connect to USB Device
A40
A39
USB4+
USB4-
- -
Directly connect to USB Device
B40
B39
USB5+
USB5-
- -
Directly connect to USB Device
A37
A36
USB6+
USB6-
- -
Directly connect to USB Device
B37
B36
USB7+
USB7-
- -
Directly connect to USB Device
B44 USB_0_1_OC#
PU
-
-
A44 USB_2_3_OC#
PU
-
-
B38 USB_4_5_OC#
PU
-
If unused, these signals can be left as NC.
Pin
Signal
PU/PD
Series
Notes
V
A30 AC_RST#
-
33 ohm
Directly connect to HAD Chip
A29 AC_SYNC
-
33 ohm
Directly connect to HAD Chip
A32 AC_BITCLK
-
33 ohm
Directly connect to HAD Chip
A33 AC_SDOUT
-
33 ohm
Directly connect to HAD Chip
B30
B29
B28
AC_SDIN0
AC_SDIN1
AC_SDIN2
-
33 ohm
Directly connect to HAD Chip
