Page 113
ICE Module
If unused, these signals can be left as NC.
Pin
Signal
PU/PD
Series
Notes
V
B89 VGA_RED
PD
-
Please refer to chapter 4
B91 VGA_GRN
PD
-
Please refer to chapter 4
B92 VGA_BLU
PD
-
Please refer to chapter 4
B93 VGA_HSYNC
-
Buffer
Please refer to chapter 4
B94 VGA_VSYNC
-
Buffer
Please refer to chapter 4
B95 VGA_I2C_CK
PU
-
Please refer to chapter 4
B96 VGA_I2C_DAT
PU
-
Please refer to chapter 4
If unused, these signals can be left as NC.
Pin
Signal
PU/PD
Series
Notes
V
A71
A72
LVDS_A0+
LVDS_A0-
-
-
Directly connect to LCD panel
A73
A74
LVDS_A1+
LVDS_A1-
-
-
Directly connect to LCD panel
A75
A76
LVDS_A2+
LVDS_A2-
-
-
Directly connect to LCD panel
A78
A79
LVDS_A3+
LVDS_A3-
-
-
Directly connect to LCD panel
A81
A82
LVDS_A_CK+
LVDS_A_CK-
-
-
Directly connect to LCD panel
B71
B72
LVDS_B0+
LVDS_B0-
-
-
Directly connect to LCD panel
B73
B74
LVDS_B1+
LVDS_B1-
-
-
Directly connect to LCD panel
B75
B76
LVDS_B2+
LVDS_B2-
-
-
Directly connect to LCD panel
B77
B78
LVDS_B3+
LVDS_B3-
-
-
Directly connect to LCD panel
B81
B82
LVDS_B_CK+
LVDS_B_CK-
-
-
Directly connect to LCD panel
A77 LVDS_VDD_EN
PD
-
Please refer to chapter 4
B79 LVDS_BKLT_EN -
-
Please refer to chapter 4
B83 LVDS_BKLT_CTR
L
- -
Please refer to chapter 4
A83 LVDS_I2C_CK
PU
-
Directly connect to LCD panel
A84 LVDS_I2C_DAT
PU
Directly connect to LCD panel
If unused, these signals can be left as NC.
Pin
Signal
PU/PD
Series
Notes
V
B97 TV_DAC_A
PD-
-
Please refer to chapter 4
B98 TV_DAC_B
PD
-
Please refer to chapter 4
B99 TV_DAC_C
PD
-
Please refer to chapter 4
