ICE Module
Page 16
2.2.5 ICE-GM45A-R10
The ICE-GM45A is shown in Error! Reference source not found. and the specifications
are listed in Table 2-6.
Table 2-6: ICE-GM45A-R10 Specification
Item Description
CPU Socket P Intel® mobile Core™ 2 Duo(Penryn), Intel®
Celeron® M
System Memory 2 x 200-pins 1066/800MHz DDR2 SDRAM SO-DIMM
Supported
System Chipset
Intel® GM45 + Intel® ICH9M
BIOS AMI BIOS
WatchDog Timer
Software programmable supports 1 ~255 sec. System
reset
Audio
HD Audio Signal to Base Board (Audio Codec on Base
Board)
MIO
4 x SATA II (Signal to Base Board)
1 x IDE channel (Signal to Base Board)
Expansion
1 x PCIe x16 signal to Base Board
4 x PCIe x1 signal to Base Board
4 x PCI, 32 bit / 33 MHz PCI bus to Base Board
USB 8 x USB 2.0 (Signal to Base Board)
Ethernet 1 x Intel 82574L GbE chipset (Signal to Base Board)
Display
Analog CRT(VGA) Integrated in Intel® GM45 (Signal to
Base Board)
18/24-bits Dual-Channel LVDS (Signal to Base Board)
HDTV-out (Signal to Base Board)
Dimensions (L x W) 125 mm x 95 mm
Power Supply Voltage ATX/AT supported
Operating
Temperature
0 ~ 60° C (32 ~ 140° F)
Operating Humidity 0% ~ 90% relative humidity, non-condensing system
