Page 109
ICE Module
near to TX side (near to destination)
as per PCI-E Device
D74
D75 PEG_TX7+
PEG_TX7- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
C78
C79 PEG_RX8+
PEG_RX8- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
as per PCI-E Device
D78
D79 PEG_TX8+
PEG_TX8- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
C81
C82 PEG_RX9+
PEG_RX9- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
as per PCI-E Device
D81
D82 PEG_TX9+
PEG_TX9- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
C85
C86 PEG_RX10+
PEG_RX10- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
as per PCI-E Device
D85
D86 PEG_TX10+
PEG_TX10- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
C88
C89 PEG_RX11+
PEG_RX11- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
as per PCI-E Device
D88
D89 PEG_TX11+
PEG_TX11- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
C91
C92 PEG_RX12+
PEG_RX12- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
as per PCI-E Device
D91
D92 PEG_TX12+
PEG_TX12- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
C94
C95 PEG_RX13+
PEG_RX13- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
as per PCI-E Device
D94
D95 PEG_TX13+
PEG_TX13- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
C98
C99 PEG_RX14+
PEG_RX14- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
as per PCI-E Device
D98
D99 PEG_TX14+
PEG_TX14- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
C101
C102 PEG_RX15+
PEG_RX15- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
