ICE Module
Page 24
3.4 Connector Pinout Row A and Row B
Table 3-3: Module Type 2 Connector Pinout Rows (A and B)
Pin Signal I/F I/O Pin Signal I/F I/O
A1 GND GND - B1 GND GND -
A2 GBE0_MDI3- GBE I/O B2 GBE0_ACT# GBE O 3.3V
A3 GBE0_MDI3+ GBE I/O B3 LPC_FRAME# LPC O 3.3V
A4 GBE0_LINK100# GBE O 3.3V B4 LPC_AD0 LPC I/O 3.3V
A5 GBE0_LINK1000# GBE O 3.3V B5 LPC_AD1 LPC I/O 3.3V
A6 GBE0_MDI2- GBE I/O B6 LPC_AD2 LPC I/O 3.3V
A7 GBE0_MDI2+ GBE I/O B7 LPC_AD3 LPC I/O 3.3V
A8 GBE0_LINK# GBE O 3.3V B8 LPC_DRQ0# LPC I 3.3V
A9 GBE0_MDI1- GBE I/O B9 LPC_DRQ1# LPC I 3.3V
A10 GBE0_MDI1+ GBE I/O B10 LPC_CLK LPC O 3.3V
A11 GND GND - B11 GND GND -
A12 GBE0_MDI0- GBE I/O B12 PWRBTN# PM I
A13 GBE0_MDI0+ GBE I/O B13 SMB_CK SMB -
A14 GBE0_CTREF GBE B14 SMB_DAT SMB -
A15 SUS_S3# PM O B15 SMB_ALERT# SMB I
A16 SATA0_TX+ SATA O B16 SATA1_TX+ SATA O
A17 SATA0_TX- SATA O B17 SATA1_TX- SATA O
A18 SUS_S4# PM O B18 SUS_STAT# PM O
A19 SATA0_RX+ SATA I B19 SATA1_RX+ SATA I
A20 SATA0_RX- SATA I B20 SATA1_RX- SATA I
A21 GND GND - B21 GND GND -
A22 SATA2_TX+ SATA O B22 SATA3_TX+ SATA O
A23 SATA2_TX- SATA O B23 SATA3_TX- SATA O
A24 SUS_S5# PM O B24 PWR_OK PM I
A25 SATA2_RX+ SATA I B25 SATA3_RX+ SATA I
A26 SATA2_RX- SATA I B26 SATA3_RX- SATA I
A27 BATLOW# PM I B27 WDT - -
A28 ATA_ACT# SATA O 3.3V B28 AC_SDIN2 HDA I 3.3V
A29 AC_SYNC HDA O 3.3V B29 AC_SDIN1 HDA I 3.3V
A30 AC_RST# HDA O 3.3V B30 AC_SDIN0 HDA I 3.3V
A31 GND GND - B31 GND GND -
A32 AC_BITCLK HDA O 3.3V B32 SPKR - -
A33 AC_SDOUT HAD O 3.3V B33 I2C_CK I2C -
A34 BIOS_DISABLE# - - B34 I2C_DAT I2C -
A35 THRMTRIP# PM O B35 THRM# PM I
A36 USB6- USB I/O B36 USB7- USB I/O
A37 USB6+ USB I/O B37 USB7+ USB I/O
A38 USB_6_7_OC# USB I 3.3V B38 USB_4_5_OC# USB I 3.3V
A39 USB4- USB I/O B39 USB5- USB I/O
A40 USB4+ USB I/O B40 USB5+ USB I/O
A41 GND GND - B41 GND GND -
A42 USB2- USB I/O B42 USB3- USB I/O
A43 USB2+ USB I/O B43 USB3+ USB I/O
A44 USB_2_3_OC# USB I 3.3V B44 USB_0_1_OC# USB I 3.3V
A45 USB0- USB I/O B45 USB1- USB I/O
A46 USB0+ USB I/O B46 USB1+ USB I/O
A47 VCC_RTC PWR -- B47 EXCD1_PERST# PCIE -
A48 EXCD0_PERST# PCIE - B48 EXCD1_CPPE# PCIE -
A49 EXCD0_CPPE# PCIE - B49 SYS_RESET# PM I
A50 LPC_SERIRQ LPC I/O
3.3V B50 CB_RESET# PM O
