ICE Module
Page 110
and place them
near to TX side (near to destination)
as per PCI-E Device
D101
D102 PEG_TX15+
PEG_TX15- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
A88
A98 PCIE_CLK_REF+
PCIE_CLK_REF- - 33 ohm Directly connect to PCIe Device or
Buffer IC
D73 SDVO_I2C_CLK - - Directly connect to SDVO Transmitter.
Using 4.7K to 10K pull up to 2.5V.
C73 SDVO_I2C_DATA - - Directly connect to SDVO Transmitter.
Using 4.7K to 10K pull up to 2.5V.
B66 WAKE0# PU Connect to PCIE wake up signal
If unused, these signals can be left as NC.
Pin Signal PU/PD Series Notes V
B68
B69 PCIE_RX0+
PCIE_RX0- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
as per PCI-E Device
A68
A69 PCIE_TX0+
PCIE_TX0- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
B64
B65 PCIE_RX1+
PCIE_RX1- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
as per PCI-E Device
A64
A65 PCIE_TX1+
PCIE_TX1- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
B61
B62 PCIE_RX2+
PCIE_RX2- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
as per PCI-E Device
A61
A62 PCIE_TX2+
PCIE_TX2- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
B58
B59 PCIE_RX3+
PCIE_RX3- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
as per PCI-E Device
A58
A59 PCIE_TX3+
PCIE_TX3- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
B55
B56 PCIE_RX4+
PCIE_RX4- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
as per PCI-E Device
A55
A56 PCIE_TX4+
PCIE_TX4- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
B52
B53 PCIE_RX5+
PCIE_RX5- - - Provide 0.1-μF AC coupling
capacitors (0402 or 0603 package)
and place them
near to TX side (near to destination)
