Page 111
ICE Module
as per PCI-E Device
A52
A53 PCIE_TX5+
PCIE_TX5- - 0.1U Cap
0.1U Cap
Directly connect to PCIe Device or
Slot.
A88
A98 PCIE_CLK_REF+
PCIE_CLK_REF- - 33 ohm Directly connect to PCIe Device or
Buffer IC
If unused, these signals can be left as NC.
Pin Signal PU/PD Series Notes V
PCI_AD[0..31] - - Directly connect to PCI Device
PCI_C/BE[0..3]# - -
Directly connect to PCI Device
C36 PCI_DEVSEL# PU -
Directly connect to PCI Device
D36 PCI_FRAME#
PU
-
Directly connect to PCI Device
C37 PCI_IRDY#
PU
-
Directly connect to PCI Device
D35 PCI_TRDY#
PU
-
Directly connect to PCI Device
D34 PCI_STOP#
PU
-
Directly connect to PCI Device
D32 PCI_PAR
-
-
Directly connect to PCI Device
C34 PCI_PERR#
PU
-
Directly connect to PCI Device
PCI_REQ[0..3]# PU -
Directly connect to PCI Device
PCI_GNT[0..3]# - -
Directly connect to PCI Device
C23 PCI_RESET# - -
PCI_RESET# should be connected to
PCI slots and PCI down devices.
C35 PCI_LOCK# PU
Directly connect to PCI Device
D33 PCI_SERR# PU -
Directly connect to PCI Device
C15 PCI_PME# PU -
Directly connect to PCI Device
D48 PCI_CLKRUN# PU -
Directly connect to PCI Device
PCI_IRQ[A..D]# PU -
Directly connect to PCI Device
D50 PCI_CLK 33 ohm Directly connect to PCIe Device or
Buffer IC
If unused, these signals can be left as NC.
Pin Signal PU/PD Series Notes V
A19
A20 SATA0_RX+
SATA0_RX- - 0.01U
Cap
0.01U
Cap
Directly connect to SATA Connector
A16
A17 SATA0_TX+
SATA0_TX- - 0.01U
Cap
0.01U
Cap
Directly connect to SATA Connector
B19
B20 SATA1_RX+
SATA1_RX- - 0.01U
Cap
0.01U
Cap
Directly connect to SATA Connector
B16
B17 SATA1_TX+
SATA1_TX- - 0.01U
Cap
Directly connect to SATA Connector
