SAS Primitive
The SAS Primitive event screen allows you to define one or more SAS primitives which
must be detected in the traffic in order to generate an action. This screen selection is
directly analogous to the SAS Primitive selection described in the Filtering section.
The detection of SAS Primitives can be limited to certain channels by selecting the
appropriate channels across the top of the screen, By default, all channels are selected.
All SAS Primitives are listed using a nested hierarchical structure, in which groups of
related primitives can be selected with a single checkbox, or the nested hierarchy can be
expanded by clicking on the [+] symbols to select individual primitives within a group.
Note: As with other screens, a shortcut method of selecting or deselecting
all channels or all primitives is provided by using CTRL-Click on any
checkbox.
