SASSuite User Manual Version 6.25
LeCroy Corporation
247
COMWAKE Settings
COMWAKE_NegLen 280 The number of bursts to send as part of this
OOB type.Each Burst is followed by an Idle.
The Burst-Idle pairs are repeated the
requested number of times, and then followed
by the Negation_length of Idle.
COMWAKE_IdleLen 160 Burst time between each OOB idle in
OOBIs.During the specified period, the
generator will send ALIGN(0) at the specified
speed.
COMWAKE_BurstLen 160 Idle time between each OOB burst in
OOBIs.During the specified period, the
generator will keep the line at electric idle.
COMWAKE_NumBursts 6 Negation time at the end of the OOB signal in
OOBIs.During the specified period, the
generator will keep the line at electric idle.
COMSAS Settings
COMSAS_NegLen 2400 The number of bursts to send as part of this
OOB type.Each Burst is followed by an Idle.
The Burst-Idle pairs are repeated the
requested number of times, and then followed
by the Negation_length of Idle.
COMSAS_IdleLen 1440 Burst time between each OOB idle in
OOBIs.During the specified period, the
generator will send ALIGN(0) at the specified
speed.
COMSAS_BurstLen 160 Idle time between each OOB burst in
OOBIs.During the specified period, the
generator will keep the line at electric idle.
COMSAS_NumBursts 6 Negation time at the end of the OOB signal in
OOBIs.During the specified period, the
generator will keep the line at electric idle.
Setting
Default
Value Description
