View Options Menu
Clicking the View Options button causes a menu to open with options for
formatting the display.
• Collapsible Idle Time - Opens a dialog box for setting the Idle time
value. By setting a value, you tell the analyzer when to collapse Idle
times and display them as grayed out strips within the Link Tracker
window. For example, if you had set the Idle time to value x then any
time an Idle time exceeded x it would be displayed as a gray strip across
the Link Tracker window.
• Tooltip Display - Opens a menu with options for adding content to
tooltips. Tooltips will display when you position the mouse pointer over
an item in the Link Tracker window. The options are:
• Tooltip Display Values
• Tooltip Display Scrambled Values
• Tooltip Displays 10 bit Codes
• Tooltip Displays Symbols
• Tooltips Displays Text Decoding
The following screenshot shows a tooltip in which all five options have
been enabled:
• Reset Column Widths - This option resets column widths to their
defaults.
Docking and Undocking the Window
You can undock the Link Tracker window by double-clicking on the blue title bar along the
left side of the window. Once undocked, the window can be dragged anywhere in the
application. To redock, double-click again on the title bar.
