New Events Menu
To add new Event buttons to the Available Events area, click the New Events button. A
menu opens with the following categories:
•
Primitives
•
Frames
•
SCSI Commands
•
SATA FIS
•
SSP Frame Header
•
SSP Information Unit
•
ATA Commands
•
ATAPI Commands
•
SATA Data Pattern
•
SAS Data Pattern
•
Bus Conditions and OOB Signals
•
Errors
•
Breakout Board Data
•
Timer
Types of Properties Dialog Boxes
Each cell and button has a properties dialog box that allows refinement of the options
being set.
Properties dialog boxes can be opened by:
•
Double-clicking a button or cell.
•
Right-clicking a button and selecting Properties from the pop-up menu.
•
Clicking the Properties button
on the toolbar.
Properties dialog boxes exist for all items in the Recording Rules page: the event
buttons, action buttons, Global State cell and Sequence cells.
