Pin-Outs for the Data In/Out Connector
The following table lists the pin-out and signal descriptions for the Data In/Out connector
on a cable that connects to the Breakout board.
Data In/Out Connector – Pin-Out
Note: (*) Pins 4 and 17 have the same function: they allow external signals
to be used to cause triggering or recording. Pins 3 and 16 are used
to transmit output signals. Pins 6, 7, 8, 9, 18, 19, 21, and 22 (data
pins) are used to define data patterns for external input signals. See
External Input Signals in Chapter 6.
Pin Signal Name Signal Description
1 RSV Reserved
2 GND Ground
3 GP OUT General Purpose Output
4 TRG IN 1 Trigger In 1
5 GND Ground
6 DATA 6 Data 6
7 DATA 4 Data 4
8 DATA 3 Data 3
9 DATA 1 Data 1
10 GND Ground
11 RSV Reserved
12 RSV Reserved
13 +5V +5 Volts, 250 mA DC Source
14 RSV Reserved
15 GND Ground
16 TRG OUT Trigger Out
17 TRG IN 0 Trigger In 0
18 DATA 7 Data 7
19 DATA 5 Data 5
20 GND Ground
21 DATA 2 Data 2
22 DATA 0 Data 0
23 GND Ground
24 RSV Reserved
25 RSV Reserved
