SASSuite User Manual Version 6.25
LeCroy Corporation
113
Assigning Actions
As shown above, you can double-click an Event or Action button to open the Properties
dialog box, and then select the Actions tab. You can then select an action from one of
the options.
The assigned action will be represented by a button to the right of the
Event button.
You can also assign an action by right-clicking on an Event or Action
button and selecting an action from the pop-up menu.
The following table shows the types of Actions you can select.
Action Comment
TRIGGER
Triggers the end of the recording.
The end point of the recording is
determined by the buffer settings in
the Recording Options General
page.
FILTER OUT
FILTER IN
Filters traffic in or out of the
recording - thereby conserving
recording buffer space.
Can not be assigned to the events
with Counters.
RESTART ALL Reinitializes counters.
