SASSuite User Manual
246
LeCroy Corporation
AutoSpeedNeg
0
When set, the generator will automatically go
throughthe speed negotiation process, for the
speed set in the PINTERFACEC_SERDES
register for the Trainer.
AutoAlignSATA
0
When set, the generator will automatically
inserting the stream 2 Align(0) primitives every
254 dwords, as specified in the SATA spec.
AutoAlignSAS
0
When set, the generator will automatically
inserting the stream Align primitives every
2048 dwords, as specified in the SAS
spec.Two Align modes can be turned on
simultaneously, to support STP
COMINIT Settings
COMINIT_NegLen
800
The number of bursts to send as part of this
OOB type.Each Burst is followed by an Idle.
The Burst-Idle pairs are repeated the
requested number of times, and then followed
by the Negation_length of Idle.
COMINIT_IdleLen
480
Burst time between each OOB idle in
OOBIs.During the specified period, the
generator will send ALIGN(0) at the specified
speed.
COMINIT_BurstLen
160
Idle time between each OOB burst in
OOBIs.During the specified period, the
generator will keep the line at electric idle.
COMINIT_NumBursts
6
Negation time at the end of the OOB signal in
OOBIs.During the specified period, the
generator will keep the line at electric idle.
Setting
Default
Value Description
