2.9.7 Bank State View
The Bank State View tab allows you to set the foreground and background colors, display
grid lines, etc., for the Bank State View displayed in the application (see
Figure 2.51 on
page 81 .)
Choosing various colors allows for easier distinction of information in the view.
The colors can be set for each of the following elements of the view:
 Main
The background and foreground colors can be selected.
 Ruler
The background and foreground colors can be selected.
 Selected Row
Only the background color can be selected.
 States
Active Power Down, Precharge Power Down, Self Refresh, Active, Idle, Unknown
and PDA Enable colors can be selected.
Note: PDA: Per DRAM Accessibility. This state makes a difference in decoding since it has an impact on
MRS timings (tMRD, tMOD). These impacts are applied on MRS timings automatically when the
modules are in this state and the "Follow MRS setting" mode is on.
 Bank State
Rank, Bank Group (DDR4) and Bank
 Layout
Check boxes to Show Grid Lines, Anti Alias drawing and Zoom Box.
 Time Stamp Cursor
The background and foreground colors can be selected.
 Header
Only the background color can be selected.
Note: The read/write density color in active state follows the RD/WR command color from the Symbol
coloring tab page.
