Teledyne LeCroy Supplemental Timing Information
168 Kibra DDR Protocol Analyzer User Manual
5.1.47 V48 - tXS-FAST SRX to a Valid Command with DLL - DDR4
Defined as the interval between Self Refresh Exit command and the next Valid command
that needs DLL. tXS‐FAST is defined as tXS_FAST = tRFC4(min) + 10ns
5.2 Supplemental Timing Information
5.2.1 tWR WR (write recovery for auto-precharge)
tWR specifies the minimum interval between the last burst write cycle and the point
where the precharge command can be issued to the same bank.
Speed
Grade 800 1066 1333 1600 1866
Min (ns) 15 15 15 15 15
