Teledyne LeCroy Waveform View
122 Kibra DDR Protocol Analyzer User Manual
 Start of the Trace
 Direction
 Forward
 Backward
 Search for
 DDR Commands
 Command Type
 Chip Select
 Bank Group
 Bank Address/MRS Number
 Read/Write/Address
 Read/Write/Address Values
 Generic Signal Values
 Signal Values
 Protocol Violations
 Protocol Violation Type
 Chip Select
 Bank Address
 Timing Violations
 Timing Violation Type
The Summary Pane displays the selections made.
Simple Search
Simple search provides the ability to search for a signal, signal group, or combination of
signals with desired values. Combined search will match when the all the conditions
match at the same time. The default search criteria for signals are don't care [X], and the
user needs to change the search criteria for any signal with the desired value.
Note: Search works on the pure value of signals without any DDR protocol specific post processing like
address mirroring/inversion.
